The system has been designed with efficient fabrication in mind.
MC 600 benefits from an inter-changeable transom/mullion profile that allows fabricators to utilise the same section for both purposes, whilst achieving consistent sight lines. Depending on requirements MC600 can either be assembled on-site as a stick built system, or alternatively part assembled in the factory. MC600 can incorporate Smart window and door inserts.
Brand | MC |
Material | Aluminium Polyamide |
Dual Colour | Yes |
Thermally Broken | Yes |
NBS Available | Yes |
U Value | 0.85W/m²K (0.7 centre pane) 1.1W/m²K (1.0 centre pane) |
Air | 600Pa |
Water | 600Pa |
Wind | 2400Pa |
Document L Compliant | Yes |
CWCT | Yes |
Glazing (mm) | 24mm - 42mm sealed units |
Typical Sightlines (mm) | 55mm |
